733.1XFL-1 Electronic Micrometer

The Starrett 733.1 Electronic Micrometer with Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. It includes output capability for data transmission. The 733.1 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. With its automatic OFF functionality, smooth friction thimble for uniform pressure, and balanced frame design, Starrett products provide comfortable and accurate measuring. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors. Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 0-1″ Range, 0.00005″ Resolution, with Case.


Range: (0 to 25.4)mm / (0 to 1)”
Resolution: 0.001 mm / 0.00005″
Accuracy: ± 0.002 mm / ± .0001″



Category:

Product Description

  • Features
  • Specifications
  • Sets
  • Accessories
  • Calibration
  • Downloads
○ IP67 protection against coolants, water, chips, dust and dirt (ranges 0-100 mm /0-4″ only)
○ Starrett no-glare satin chrome finish on thimble and sleeve
○ Micro-lapped carbide measuring faces
○ Large, easy-to-read 7 mm (0.275″) high contrast LCD digital readout
○ Balanced and tapered frame
○ Extremely hard and stable one-piece spindle
○ Auto Off after 20 minutes of nonuse
○ Inch/millimeter conversion on English versions
○ Smooth friction thimble for uniform pressure
○ Measurement HOLD button
○ Zero at any position
○ Retain and return to true zero reading
○ Spindle lock
○ Data Output
○ PRESET button to install any reading at any position
○ Ability to install minimum and maximum limits
Micrometer Type Outside
Range (0 to 25.4)mm / (0 to 1)”
Resolution 0.001 mm / 0.00005″
Accuracy ± 0.003 mm / ± 0.0001″
Anvil / Spindle Material Carbide
Anvil Type Flat
Spindle Type Flat
Lock Nut Type Lever
Thimble Type Friction
Thimble Graduations English
Display Type LCD
SPC Output Yes
Case Type Plastic
No. S795.1AXFLZ
Range (0 to 75)mm / (0 to 3)”
Description Electronic micrometer set (set of 3)
Includes 795.1XFL-1, 795.1XFL-2, 795.1XFL-3
No. S795.1BXFLZ
Range (0 to 100)mm / (0 to 4)”
Description Electronic micrometer set (set of 4)
Includes 795.1XFL-1, 795.1XFL-2, 795.1XFL-3, 795.1XFL-4

Sets available upon request


795.1SCM SmartCable to multiplexer
795.1SCKB USB cable to PC (In focused window)
795.1SCU SmartCable with USB keyboard output
PT994292 Two 3-Volt Batteries, CR2032

Calibration and Repair Services

MRM provides Calibration and Repair Services for the
733.1XFL-1 Electronic Micrometer

For a quote, please email us at  [email protected]
