Product Description
- Features
- Specifications
- Dimensions
- Accessories
- Downloads
- Calibration
| ○ The minimum value holding function provides the easy detection of hole diameter |
| ○ Up to three sets of master value and upper/lower tolerance value can be memorized |
| ○ An analog bar indicator is integrated to enhance the intuition in reading |
| ○ GO/±NG judgment is performed by setting the upper and lower tolerances |
| ○ Up to four rods (250 mm or 500 mm) can be used |
| ○ Origin-set, Zero-Setting, Presetting, Power on/off |
| ○ Inch/mm conversion, Data output, GO/±NG tolerance judgment |
| ○ Alarm: Low battery voltage, scale contamination, over-flow error, tolerance limit setting error |
| Range |
(100 to 160) mm / (4 to 6.5)” |
| Resolution |
0.001 mm / 0.00005″ |
| Accuracy |
0.003 mm / 0.00012” |
| Probe |
152.4 mm / 6″ |
| Display |
LCD |
| Dust/Water Protection Level |
Conforming to IP53 |
| Included Items |
|
| 938882 |
Battery SR44 (1 pc.) |
| Battery Life |
Approx. 9 months for normal use |
| Optional Items |
|
| 21DZA089 |
Extension rod 250 mm / 10″ |
| 21DZA081 |
Extension rod 500 mm / 20″ |
| 516-118-10 |
Origin setup metric rectangular gage block set |
| 516-119-10 |
Origin setup metric square gage block set |
| 516-120-26 |
GB calibration kit for series 511 bore gage. (9 pcs GB and plain jaw, 160 mm holder) |
| 905338 |
SPC cable (1m) |
| 905409 |
SPC cable (2m) |
Calibration and Repair Services
MRM provides Calibration and Repair Services for the
511-522 Mitutoyo Bore Gauge, Absolute Digimatic
For a quote, please email us at [email protected]
