Mitutoyo Absolute-Snap Caliper

573-282-30 Mitutoyo Digimatic Snap Caliper 150 mm , 6″

The 573-282-30 ABSOLUTE Snap caliper features a spring loaded mechanism in the slide to perform fast, accurate measurements along with quick go/no-go decisions. Two sets of jaws, upper and lower, allow for precise outside and inside dimensions. Step and depth measurements are possible with the depth bar.

It comes with a one-year manufacturer’s warranty.
Shop for 573-282-30 Digital Caliper at MRM Metrology, and save.
Buy 573-282-30 Caliper now for the best price in Canada.

Email us for the lowest price.
Click on [email protected] to request a quotation.

SPC
Absolute


Other Models

SKU: 573-282-30 Category:

Product Description

  • Features
  • Specifications
  • Dimensions
  • Accessories
  • Downloads
  • Calibration

○ Measures pieces that standard calipers cannot measure
○ Jaws are tipped with carbide for better accuracy and longer performance
○ SPC output function offers quick and easy data management in real time
○ ABSOLUTE (ABS) linear scale eliminates the need for setting the origin point every time the micrometer is powered on; overspeed errors are also eliminated
○ Origin Set, Zero Setting, Power On/Off, Data Output and inch/mm conversion
○ Alarm: Low Voltage, Counting Value Composition Error
○ Constructed of hardened stainless steel for better durability and longevity
○ Supplied in fitted plastic case

Range (0 to 150) mm , (0 to 6)”
Resolution 0.01 mm , 0.0005″
Accuracy ± 0.001″
Mass 213 g
Measuring Force (7 to 14) N , (700 to 1400) gf
Jaw Retraction 2 mm
Display LCD
Length Standard ABSOLUTE electrostatic capacitance type linear encoder
Max. Response Speed Unlimited
Repeatability 0.0005″
Warranty One year limited manufacturer’s warranty

573-181 sheet


Included Items
Battery (938882) SR44 (1 pc)
Battery Life Approx. 3.5 years under normal use
Optional Items
959149 SPC cable with data switch (1m / 40”)
959150 SPC cable with data switch (2m / 80”)
959143 Data hold unit

○ A Certificate of Calibration is included when calibration services are ordered from MRM Metrology Inc.
○ Use CAL 573-282-30 when requesting calibration services from MRM Metrology.

Calibration and Repair Services

MRM provides Calibration and Repair Services for the
573-282-30 Mitutoyo Digimatic Snap Caliper

For a quote, please email us at  [email protected]
