| ○ Constant and low measuring force mechanism in the thimble |
| ○ Adjustable measuring force accommodates various kind of work materials |
| ○ The measurement-value hold function automatically retains the data at a specified measuring force, ensuring accuracy |
| ○ Non-rotating spindle and the new ratchet friction thimble |
| ○ Speedy spindle feed of 10 mm/rev. and 0.4” /rev for inch/metric model |
| ○ With absolute linear scale |
| ○ With SPC data output |
| ○ Supplied in fitted plastic case |
| ○ Origin-set |
| ○ Power ON/OFF |
| ○ Data hold, Data output |
| ○ With a standard bar to set the origin point |
| Range | (0 to 0.4)” |
| Resolution | 0.001 mm /0.00005″ |
| Accuracy | ± 0.0001″ |
| Measuring Force | (2 to 10) N |
| Flatness | 0.3 µm / 0.000012” |
| Parallelism | 2 µm / 0.00008” |
| Battery | 938882 |
| Display | LCD |
| Mass | 340 g |
| Battery | 938882 |
| Battery life | 3 years under normal use |
| 937387 | SPC cable 1 m / 40″ |
| 965013 | SPC cable 2 m / 80″ |
It comes with a one-year manufacturer’s warranty.
Shop for 227-201-20 Digimatic Micrometer at MRM Metrology and save.
Buy 227-201-20 now for the best price in Canada.
Click on [email protected] to request a quotation.
Calibration and Repair Services
MRM provides Calibration and Repair Services for the
227-215-20 Mitutoyo Outside Micrometer, Digimatic
For a quote, please email us at [email protected]
