143-104 Mitutoyo Mechanical Caliper-Type Micrometer (75 to 100) mm

The 143-104 Mechanical Caliper-Type Micrometer delivers precise measurements on recessed features which regular micrometers are unable to achieve. The micrometer features jaws constructed of hardened steel with carbide measuring surfaces and a hardened steel spindle to take precise measurements on recessed features.

The micrometer’s ratchet stop mechanism provides a constant measuring force on the spindle to ensure accurate, repeatable measurements. The combination of the ratchet thimble and speeder enables a rapid spindle feed when measuring extensive dimensions. Easy one-handed measurements can be achieved.

It comes with a one-year manufacturer’s warranty.
Shop for 143-104 Mechanical Caliper-Type micrometer at MRM Metrology, and save.
Buy 143-104 Caliper-Type micrometer for the best price.

Email us for the lowest price.
Click on [email protected] to request a quotation.


Other Models
SKU: 143-104 Category:

Product Description

  • Features
  • Specifications
  • Dimensions
  • Accessories
  • Downloads
  • Calibration

○ Ratchet stop mechanism provides an audible click to ensure measurement is being performed at a constant pre-set force.
○ Carbide-tipped measuring tips resist wear for better accuracy over time.
○ Frame has a baked enamel finish for more durability.
○ Satin chrome finish on the sleeve and laser etched scale on thimble for easier reading.
○ Includes a standard bar except.
○ Supplied in a plastic, fitted case.

Range (75 to 100) mm
Graduation 0.01 mm
Accuracy ± 8 µm
Flatness 0.3 µm
Parallelism 3µm or less
Mass 330 g
Ratchet/Thimble Ratchet Stop
Measuring Faces Carbide tipped
Warranty One-year limited manufacturers warranty

caliper-type micrometer specifications metric
caliper-type micrometer specifications inch metric

343-351-30 dimension

○ A Certificate of Calibration is included when calibration services are ordered from MRM Metrology Inc.
○ Use CAL 143-104 when requesting calibration services from MRM Metrology.

Calibration and Repair Services

MRM provides Calibration and Repair Services for the
143-104 Mitutoyo Mechanical Caliper-Type Micrometer

For a quote, please email us at  [email protected]
