| ○ Weighing, Parts Counting, Checkweighing |
| ○ Animal/Dynamic Weighing, Vehicle Weighing |
| ○ Transflective graphic LCD with white backlight, 240 x 96 pixels |
| ○ AC power (included) |
| ○ Easy access communication port including RS232 (included), USB, Ethernet and second RS232 or RS485 (accessories) |
| ○ GLP/GMP data output with real-time clock |
| ○ IP66/NEMA 4X stainless steel housing and mounting bracket |
| ○ Checkweighing lights with selectable operation and audible signal settings, sealed front panel |
| ○ 5 operating languages (English, Spanish, French, German and Italian) |
| ○ Selectable environmental and auto-print settings |
| ○ Stability and overload/underload indicators |
| Capacity |
Capacity Up to 998000 (t, kg, g or lb) |
| Resolution |
50,000 |
| Outputs |
3 In/4 Out digital I/O |
| Protection Rating |
IP66 |
| Display |
Graphic LCD |
| Power |
AC Power (Included) |
| Tare Range |
To capacity by subtraction |
| Units of Measurement |
Kilogram; Pound; Ounce; Pound:Ounce; Gram; Metric Tonnes |
| Working Environment |
(-10 to 40)°C, 85% RH, Non-condensing / (14 to 104)°F, 85% RH Non-condensing |
| H x L x W |
(232 x 86 x 283) mm / (9.1 x 3.4 x 11.1)” |
| Weight |
3 kg / 6.6 lb |
| 80500552 |
Cable, RS232, CKW TxxXW |
| 30064203 |
Printer, Impact, SF40A, AM |
| 72209340 |
Column Adapter, SST, T32XW T51XW T71XW |
| 80251992 |
Printer, Thermal, STP-103, US |
Calibration and Repair Services
MRM provides Calibration and Repair Services for the
T72XW Ohaus Indicator
For a quote, please email us at [email protected]
