| â—‹ Intuitive menu |
| â—‹ Suite of Mathematical Functions for each channel |
| â—‹ Auto colour change for in/out limit range |
| â—‹ User selectable bar panel or text display |
| â—‹ Auto course / fine resolution |
| â—‹ Gauging Mode |
| â—‹ Peak hold facility |
| â—‹ Data logging facility |
| â—‹ RS232 Connectivity |
| ○ 0.01 μm display resolution |
| â—‹ Available for Digital probes, Linear Encoders, Encoder Input modules and laser sensors |
| â—‹ Discrete I/O |
| Performance and Functions | Â |
| Number of Transducers | 1 or 2 |
| Display | 1 or 2 Channels |
| Length / Resolution | ±xx.xxxxx (mm) ±xx.xxxxx inches |
| Indications | mm / inch, Lower and Upper Limits, Out of Range, Measurement Type and Mode |
| Keypads | Print, Zero, Preset, Peak, Hold Track, Menu |
| Measurement Type Data Logging | A, B, A+B, (A+B)/2, (A+B)2, (B+A)/a 10,0000 readings via discrete inputs or 1 ms to 24 hour time interval |
| Inputs and Outputs | Â |
| Orbit® Interface | Yes |
| Serial ACSII Interface | Yes |
| Inputs | Six isolated |
| Outputs | Six isolated |
| Analogue Output | 2 User selectable Voltage or 4-20 mA |
| Power and Environmental | Â |
| Operating Voltage | 24 VDC ± 10% |
| Power for Transducers | 5 VDC up to 2 transducers |
| Sealing Front Panel | IP65 |
| Sealing Case | IP51 |
| Sealing Rear Connections | IP51 |
| Operating Temperature | (5 to 50) °C |
| Storage Temperature | (-20 to 50) °C |
| EMC | Immunity EN61000-6-2 Emissions EN61000-6-3 |
| Mechanical | Â |
| Mounting | Bench or Panel |
| Dimensions WxHxD | Without bezel 132x67x160 / With Bezel 144x76x177 |
| Dimensions WxHxD | Without bezel: 132x67x160 / With Bezel: 144x76x177 |
â—‹ A Certificate of Calibration is included when calibration services are ordered from MRM Metrology Inc.
â—‹ Use CAL SI 3500 when requesting calibration services from MRM Metrology.
Calibration and Repair Services
MRM provides Calibration and Repair Services for the SI 3500 Solartron Metrology Digital Readout
For a quote, please email us at  [email protected]
