62 MAX Mini Fluke Infrared Thermometer

The Fluke 62 MAX Infrared thermometer delivers many of the features of the Fluke 62 MAX+ but features a single laser and 10:1 distance to spot ratio. You can use Fluke 62 MAX to perform non-contact temperature measurements on transformers, motors, pumps, panels, breakers, compressors, ducts, steam lines, valves, and vents. It is small in size and extremely easy to use. The single laser helps you pinpoint the target for more accurate readings and makes it easier to measure temperatures in hard to reach areas. With its IP54 rating for dust and water resistance, you can rely on the Fluke 62 MAX to deliver accurate, repeatable temperature measurements, rain or shine, in even the dirtiest and dustiest industrial sites. And it’s rugged enough to take a 3-meter drop so no worries even if you work from a ladder




Temperature Range (-30 to 500)°C / (-22 to 932)°F
Resolution 0.1°C
Accuracy ± 3 °C (-30 < -10 °C) ; ± 2 °C (-10 to < 0 °C) ; ± 1 °C (0 to 650 °C) or 1 % of Reading, whichever is greater

Product Description

  • Features
  • Specifications
  • Dimension
  • Accessories
  • Downloads
  • Calibration

○ Highly accurate infrared thermometer for measuring temperatures
○ Provides a 10:1 Distance to spot ratio
○ Offers single laser targeting for accurate and repeatable measurements
○ Features IP54 rating against dust and moisture
○ High and low alarms for rapid detection of temperatures outside the limits
○ Withstands a 3 m / 9.8 ft drop
○ Offers small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
○ Features a large, backlit display to make data easier to read, even in dark areas
○ Displays the minimum, maximum or average temperature, or the difference between two measurements
○ Powered by a single, standard AA battery
Temperature Range (-30 to 500)°C / (-22 to 932)°F
Resolution 0.1°C
Accuracy ± 3 °C (-30 < -10 °C) ; ± 2 °C (-10 to < 0 °C) ; ± 1.5 °C (0 to 650 °C) or 1.5 % of Reading, whichever is greater
Response Time < 500 ms (95% of reading)
Spectral Response (8 to 14) microns
Emissivity (0.10 to 1.00)
Optical Resolution 10:1 (calculated at 90% energy)
Display Resolution 0.1°C / 0.2°F
Repeatability of Readings ± 0.8 % of reading or < ± 1°C (2°F), whichever is greater
Power AA battery
Battery life 10 hours with laser and backlight on
Operating Temperature (0 to 50)°C / (32 to 122)°F
Storage Temperature (-20 to 60)°C / (-4 to 140)°F, (without battery)
Operating Humidity (10 to 90) % RH non-condensing at 30°C / 86°F
Operating Altitude 2000 meters above mean sea level
Storage Altitude 12,000 meters above mean sea level
IP Rating IP 54 per IEC 60529
Drop Test 3 meters
Vibration and Shock IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms
Electromagnetic Compliance IEC 61326-1: Portable electromagnetic equipment
Safety IEC 61010-1: Pollution degree 2, IEC 60825-1: Class 2

Dimensions (175 x 85 x 75) mm / (6.88 x 3.34 x 2.95)”
Mass 255 g / 8.99 oz

○ Single laser infrared thermometer
○ 10:1 spot

Calibration and Repair Services

MRM provides Calibration and Repair Services for the
62 MAX Mini Fluke Infrared Thermometer

For a quote, please email us at  Service@MRMmetrology.com
