| ○ Proven ABSOLUTE sensor |
| ○ Rated to IP66 water- and dust-proofing standard and oil resistance improved |
| ○ The slim body design is advantageous for multi-point measurements |
| ○ Improvement in workability with the LCD readout-rotation function |
| ○ Built-in tolerance judgment function |
| ○ Switchable resolution, Built-in hold/preset function |
| ○ Waterproof data output connector |
| ○ Zero-setting, Presetting, Direction switching, Tolerance judgment |
| ○ Display hold, Data output, inch/mm conversion |
| ○ Alarm: Over-flow error, Tolerance limit setting error |
| ○ Alarm: Low voltage, Counting value composition error |
| Range | (0 to 5) mm |
| Resolution | 0.001 mm |
| Accuracy | ± 0.003 mm |
| Display | LCD |
| Length Standard | ABSOLUTE electrostatic capacitance type |
| Max. Response Speed | Unlimited |
| Measuring Force | 2.5 N or less |
| Battery | SR44 (1 pc.), 938882 |
| Battery Life | Approx. 7000 hours under normal use |
| Stem | Ø 8 mm |
| Thread | M2.5×0.45 Thread |
| Type | ISO/JIS |
| Warranty | One year limited manufacturers warranty |
| Replacement | 543-575-10 replaces 543-575 |
| Included | |
| 938882 | SR44 Battery (1 pc.) |
| Optional | |
| 21EZA105 | Lifting knob (for ISO/JIS model) |
| 21EZA150 | Lifting knob (for AGD model) |
| 21EZA146 | Lug (for JIS/ISO model) |
| 238774 | Lug (for AGD model) |
| 02ACA376 | Rubber boot (for ID-N, NBR) |
| 238774 | Rubber boot (for ID-N, silicon) |
| 125317 | Rubber boot (for ID-B, NBR) |
| 21EAA212 | Rubber boot (for ID-B, silicon) |
| 21EAA194 | SPC cable (40” / 1m) |
| 21EAA190 | SPC cable (80” / 2m) |
| 21EAA210 | Bifurcated connecting cable with zero-setting terminal (40”/1m) |
| 21EAA211 | Bifurcated connecting cable with zero-setting terminal (80”/2m) |
○ A Certificate of Calibration is included when calibration services are ordered from MRM Metrology Inc.
○ Use CAL 543-575-10 when requesting calibration services from MRM Metrology.
Calibration and Repair Services
MRM provides Calibration and Repair Services for the
543-575-10 Mitutoyo Digimatic Indicator
For a quote, please email us at [email protected]
