The 114-124 V-Anvil Micrometer measures the outside diameter of cutting heads (such as taps, reamers, end mills) with an odd number of flutes. With Ratchet Stop for constant force. For 5 Flutes cutting head.
It comes with a one-year manufacturer’s warranty.
Shop for 114-124 V-Anvil Micrometer at MRM Metrology, and save.
Buy 114-124 now for the best price in Canada.
Email us for the lowest price.
Click on [email protected] to request a quotation.
| â—‹ Measures the outside diameter of cutting heads(such as taps,reamers,end mills) with odd number of flutes |
| â—‹ With Ratchat Stop for constant force |
| â—‹ Supplied with setting standard |
| â—‹ V-anvils with a centerline grove are available |
| â—‹ For measuring pitch diameters of of taps which have a small diamter by using single-wire method |
| â—‹ Supplied in fitted plastic case |
| Range | (65 to 85) mm |
| Graduation | 0.01 mm |
| Accuracy | ± 0.007 mm |
| Setting Standards | Ø70 mm |
| Remarks | Without Groove |
| Mass | 760 g |
| Flatness (spindle/anvil) | 0.6 µm / 0.000024″; 1.3 µm / 0.00005″ |
| Spindle face | Carbide tipped |
â—‹ A Certificate of Calibration is included when calibration services are ordered from MRM Metrology Inc.
â—‹ Use CAL 114-124 when requesting calibration services from MRM Metrology.
MRM provides Calibration and Repair Services for the
114-124 Mitutoyo V-Anvil Micrometer
For a quote, please email us at  [email protected]
